[1S1P]
| NO. | Item | Specification | Remark |
| 1 | Typical Capacity | 3450 mAh | Reference only |
| 2 | Niminal Capacity | 3350 mAh | 0.2CA Discharge at 25℃ |
| 3 | Minimum Capacity | ≧3300 mAh | 0.2CA Discharge at 25℃ |
| 4 | Niminal Voltage | 3.6V | |
| 5 | Watt-Hour Rating | 12.42Wh | 依3450mAh來標示 |
| 6 | Weight | About 50g | |
| 7 | Charging Method | CC/CV | |
| 8 | Charging Voltage | 4.2±0.03V | |
| 9 | Over Discharging Cut-off Voltage |
2.3V± 0.50V | For per serie (from cell terminal) |
| 10 | Pack Dimension | Width: Max 20.5mm Height:Max 69.0mm Wire(without Connector): 50.0±5mm |
歡迎來電洽詢
鋰電池應用，可攜式設備相關規劃
